Shure ULXD 4Q Single Channel Receiver

Add to Quote

It is ideal for professional sound reinforcement applications in large live venues and houses of worship, as well as A/V installations in conference, educational, and corporate facilities. Compatible with a wide selection of Shure transmitters and mic capsules, it delivers pristine 24-bit/48 kHz digital audio, capturing every detail with clarity, accurate low end, and crisp transient response.

For Large Venues & A/V Installations
1 x Digital Audio Channel, 1/2 Rackspace
64 MHz Tuning Range
Expandable up to 60 Channels
1 x Ethernet Port
Secure AES-256 Encryption

Additional information

Weight 2 lbs
Dimensions 6.7 × 1.7 × 7.8 in
Full Technical Specs

Receiver type: Tabletop
Mounting Options: Rackmount, Tabletop (With Included Hardware)
Rackmount Size: 1 RU (½ rack)
Antenna : 2 x 1/2 Wave External, BNC (Rear-Mount)
Number of Audio Channels: 1
Audio I/O: 1 x XLR 3-Pin Male Balanced Output1 x 1/4" TRS Female Balanced Output
Gain Range: -18 to +42 dB (1 dB Steps)
Pad: 30 dB
Audio Output Level: XLR Output: +18 dBV (Line Level)/XLR Output:/-12 dBV (Mic Level)/1/4" /Output: +12 dBV (Consumer Level, Instrument Level)
Phantom Power Protection: On 1/4", XLR Outputs
Frequency Response: 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
Network I/O: 1 x RJ45 (10/100 Mb/s)
Network Protocols : DHCP, Manual IP
Impedance: XLR Output: 100 Ohms (Balanced)
Approx. RF Sensitivity: -98 dBm
Adjacent Channel Isolation: >70 dB
Spurious: Rejection: >80dB
Power Requirements: AC/DC Power Adapter
AC/DC Power Adapter: 15 VDC at 600 mA (included)
AC Input Power: 100 to 240 VAC , 50 / 60 Hz at 250 mA
Display & Indicators: 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)/ 2 x Multi-Segment LED (AF Level, Output Level, Peak)
Operating Temperature: 0 to 122°F / -17 to 50°C
Storage Temperature: -20 to 165°F / -28 to 73°C
