Astera Pixel Brick

Our next-generation multi-purpose light. In addition to being a battery-powered uplight and PAR with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes. With about 10cm edge length and 1kg weight, it is small and lightweight while still featuring a powerful output of high-quality light. The PixelBrick can be used for many stage, film and TV applications.

Titan LED Engine
Combines several units into a cluster
Creates shapes using various mounting accessories
Filters and domes to create a different beams and looks
Airline Track for accessories
Backside display with dedicated color and brightness buttons
Removable bracket
DirectApp control (No Asterabox required)

Additional information

Weight 2.47 lbs
Dimensions 3.6 × 3.6 × 3.7 in
Accessories

1x tru1 6', Flood filter, beam softner, pixelbrick connect, powerbox w/ 8 cables

Options

Accessory Kit

Full Technical Specs

LED Engine: Titan LED Engine
Colors: RGB Mint Amber
Total LED Power: 15W
Power Draw: 12W
Light output: 2700K, 3200K, 5500K:* 388lm, 450lm, 375lm
CRI(Ra)/TLCI 3200-6500K*: ≥96
Beam Angle: 13°
Strobe: 0 – 25Hz
Pixels: 1
*Typical value
Electrical
Battery Lifetime: 70 % after 300 cycles
Battery Runtime: up to 20 hours
Charging Time (nominal): 4 hrs
Input Voltage: 24VDC
Input Current: 0.8A
Control
Wired DMX: Yes (via PWB-2-86)
CRMX Receiver: Built-in
Wireless Frequencies: CRMX 2.4GHz, UHF, Bluetooth
Range (m/yds): 300 / 330yds
